Airbus A320 Home Cockpit Shell design and implementation -Part II

Okan Saçlı

Oct 23, 2020

Airbus A320 Home Cockpit Shell design and implementation -Part II

The complete cabin has been modeled in 3D as seen below. This design is the result of many days and nights hard work. A short video of the design can be seen at this link. The only source of information available was some photos over the net. This design was done in year 2003 by the way. Before starting with the production I wanted to see the complete design in 3D so that's how I did it. Branching off from this 3D-Design I produced my many 2D workshop drawings for the actual

2,906 views2 comments

Fire Fighting and Prevention Project - Pakistan Faysalabad

Okan Saçlı

Oct 20, 2020

Fire Fighting and Prevention Project - Pakistan Faysalabad

This fire fighting project is located in Faysalabad - Pakistan. This plant is the first investment of Hayat Group in Pakistan. Acting as the project manager we completed the installation and commisioing of the water based sprinkler systems (according to NFPA13), foam based extinguishing systems, CO2 based extinguishing systems with local applications, electronic fire detection and activation systems, underground hydrant lines and hose reel cabinet systems on a turnkey EPC bas

50 views0 comments

Airbus A320 Throttles for Home Cockpit - Rework

Okan Saçlı

Jun 29, 2020

Airbus A320 Throttles for Home Cockpit - Rework

I have designed and manufactured my throttles back in 2004 as seen at this link. The initial design was plastic levers without reverse locking mechanism and aluminium body and non moving plastic based trim wheels. Recently I have decided to upgrade the throttle set, so that I have more realistic looking levers and try to implement the reverse thrust locking levers as well. The design is an existing one (with all the necessary STL files included) which was officialy purchased

848 views1 comment

Natural Gas Pressure Reduction Station (PRS) project completed

Okan Saçlı

Feb 20, 2020

Natural Gas Pressure Reduction Station (PRS) project completed

The PRS (pressure reduction station) for the Canadian gas grid is completed successfully in Gebze workshop in Turkey. As reported previously, the design maximum inlet pressure is 99.3 bars and the station outlet pressure is set at 5.5 bars range. The special design containerized, flexible PRS solution was done by Palmet group and the design was approved by Petra engineering of Canada (design according to CSA) The container was designed in such a way to work extreme low temper

216 views0 comments

Natural Gas Pressure Reduction Station (PRS) for the Canadian gas grid

Okan Saçlı

Jan 21, 2020

Natural Gas Pressure Reduction Station (PRS) for the Canadian gas grid

We are currently manufacting a PRS (Natural gas pressure reduction station) which will have a maximum inlet pressure of 99.3 bars and an outlet pressure of 5.5 bars to be used in the Canadian gas grid. It will be a containerized flexible design which will be shipped from Turkey to Canada in a built package configuration. The design of the PRS (both the mechanical skid and the container) was done inhouse by Palmet Group and was approved and stamped by Petra Engineering of Cana

81 views0 comments

Okan Saçlı

Oct 17, 2019

Home Cockpit Flying

Short update from the latest developments in my #airbus #a320 #homecockpit. Things are improving. There are still lots to improve with the software side of things (JeeHell FMGS). I had issues with my P3D frame rates which was also effecting the logic software, so made some improvements in terms of settings. Using ORBX scenery and ORBX LOWI (which is a heavy load airport in terms of graphics) i am able now to get around 40 FPS steady so it is good now. I do have plans for bett

463 views3 comments

Flight Simulator PC System Setup (update 07.01.2021)

Okan Saçlı

Sep 7, 2019

Flight Simulator PC System Setup (update 07.01.2021)

Below is the list of desktop PC's and their configurations (CPU,RAM and Graphics Card) and the simulator components that are running on them. All PC's are running the latest windows10 x64. I will publish a seperate blog entry to the electronics interfacing system used in the sim. #airbus #a320 #airbusa320 #simulator #simulation #setup #pc #computer #datacenter #turkey #turkish #engineering #challenge #homecockpit #homesimulator PC1 - P3D CPU:i7-7700k 4.20GHZ RAM:16 GB RAM Gra

480 views0 comments

Airbus A320 Korry Type Buttons - Before 3D printing

Okan Saçlı

Sep 3, 2019

Airbus A320 Korry Type Buttons - Before 3D printing

Before having a 3D printer, I used to make my "korry like" buttons using microswitches, Kingbright DE/2ID type led bars and some small plexi plates working as support structures as you can see in this blog entry and photos. Note that these buttons are dated back to 2004-2005 , so lots have changed since then. You may see how I do my korry buttons and find a comprehensive tutorial via this link All buttons are hooked on the opencockpits I/O boards and coded via SIOC to speak w

774 views0 comments

Okan Saçlı

Sep 2, 2019

Airbus A320 Throttles for my cockpit

I designed and manufactured my throttle levers back in 2004. Below are some photos from the design phase, manufacturing phase and installation in place. Firstly, I have designed in 2D environment, looking at various photos available in the internet as I never had the change to go in the real cockpit to measure things out. After I was satisfied with the 2D design , I did a 3D design to get a feeling of how the complete product would look like in reality. All went good, the cas

835 views0 comments

Airbus A320 Emergency Gravity Gear Extension Handle - 3D printed

Okan Saçlı

Aug 31, 2019

Airbus A320 Emergency Gravity Gear Extension Handle - 3D printed

Thanks to Thingiverse and flykarli, I found the stl file to print an emergency gravity gear extension handle for the simulator. Although it is possible to integrate a mechanism with a rotary encoder to simulate manual gear extension in case of gear failure inhibited, however I think current status of FSUIPC does not allow a manual extension, so for now it is installed on the pedestal as a dummy (visual only). If I can work out a logic with FSUIPC offsets I will definetly take

275 views0 comments

Airbus A320 Home Simulator - The early days of the Project

Okan Saçlı

Aug 31, 2019

Airbus A320 Home Simulator - The early days of the Project

Here are some photos from 2003, the very beginning of the project. I have decided to build my simulator back in 2003 in Switzerland. I was working as a project manager for the 3G rollout of ORANGE communications back then. In the photos you can see the very early stages, the first steps in building my Airbus A320 project. There are lots and lots of hours invested in the development of the simulator, most of the steps by trial and error. As of today it is fully flyable needs s

233 views0 comments

Data Center Air-to-Air Cooling (20 x 150 kW) Project Completed

Okan Saçlı

Aug 8, 2019

Data Center Air-to-Air Cooling (20 x 150 kW) Project Completed

The project for the installation, commisioning and heat load testing for 20 nos. of 150 kW air-to-air cooling system (total of 3 MW cooling) has been successfully completed. The project is located in Ankara, Turkey in Kredi Kayıt Bürosu Tier4 datacenter. Palmet Engineering was the main contractor on an EPC basis of the complete phase-I of this huge datacenter complex. In phase one we have already installed 20 nos. of 150 kW cooling system for white space 1 and whitespace 2. T

66 views0 comments

Okan Saçlı

Jul 12, 2019

Airbus A320 Home Simulator Video (July 2019)

Finally a complete video of my full Airbus A320 home cockpit setup. Video is from July 2019. Almost all components are fully functional now running JeeHell software. This was a first attempt to use a video editor, so things may be a bit shaky :) New steps are optimizing stuff in the sim and hopefully better (HD) visuals. #airbus #a320 #airbusa320 #airbussimulator #airbuscockpit #simulator #cockpit #engineering #engineerslife #diy #turkey #turkish #engineering #aviation #cloud

153 views0 comments

Data Center Air-to-Air cooling (20 x 150 kW) Project Progress

Okan Saçlı

Mar 12, 2019

Data Center Air-to-Air cooling (20 x 150 kW) Project Progress

Our project for the installation, commisioning and heat load testing for 20 nos. of 150 kW Air to Air cooling system has begun recently. The project is located in Ankara, Turkey in KKB datacenter. The cooling units are manufactured by #flaktgroup #turkey, each unit consists of 13 parts total weight approximately 11 tons. The parts are assembled on site on pre fabricated steel support beams (which reside over seismic isolators). For the purpose of installation, a special beam

74 views0 comments

Crane for the Construction of a TV Broadcasting Tower - Project from 1998

Okan Saçlı

Feb 4, 2019

Crane for the Construction of a TV Broadcasting Tower - Project from 1998

This project is from 1998, where I designed, manufactured and installed a special purpose crane for the manufacturing of the inverse conical concrete section / platform and the steel structure above the conical platform for aluminium facade cladding anf glass structure (upper level of platform is +144.729m) at Ender TV Broadcasting tower located in Beylikduzu - İstanbul. The height of the concrete part of the tower is +163.300 m above +0.00. The foundation is located at -9.50

31 views0 comments

First Construction Site Project - Cimsa Mersin Cement Factory

Okan Saçlı

Feb 4, 2019

First Construction Site Project - Cimsa Mersin Cement Factory

As a junior engineer freshly graduated from university, my first construction project abroad (away from Istanbul) was in Mersin Turkey, Cimsa Cement Plant. We built 3 nos. of concrete silos for OPC (Ordinary Portland Cement), I was responsible for the design, manufacturing and installation of all the steel works The steel works were ; inside the silo on the bottom a conical bunker structure with precast concrete blocks, at the upper level of the silo for the installation plat

33 views0 comments

Okan Saçlı

Feb 4, 2019

First Engineering Project from 1994

This was my first ever engineering project which was the design, manufacturing and construction of a stainless steel chimney for a battery plant in Kurtköy Istanbul. It was an ~80cm inner diameter stainless steel chimney with rock wool thermal insulation and aluminium cladding on the outside. The support steel structure was also designed by me. I was working at Endem Construction back then as a junior mechanical engineer, fresh out of the university. Even back then I knew tha

25 views0 comments

Natural Gas Fired CCGT Power Plant Project ALES

Okan Saçlı

Jan 29, 2019

Natural Gas Fired CCGT Power Plant Project ALES

This project is located in Aydın, Turkey. It was completed and commisioned in 2012. I was the acting project and construction manager for this 63 MWe Natural Gas Fired Combined Cycle power plant. Some of the key figures and critical items are follows; 45.000 m2 landplot GE LM-6000 PC Sprint NG Turbine + Generator Aalborg Heat Recovery Steam Generator GE Thermodyn 6-7 MC9 14.150 kW Steam Turbine + Generator SPIG Water Cooling Tower NG PRMS Station 11.5 kV / 154 kV Grid connect

31 views0 comments

TIER III Data Center Project - Vakıfbank Istanbul Umraniye

Okan Saçlı

Jan 29, 2019

TIER III Data Center Project - Vakıfbank Istanbul Umraniye

This project is located in Umraniye - İstanbul. It was a fit out project where the car parking area located at the basement of a building was totaly knocked down and converted to a TIER III datacenter. Total construction area, including outside genset and chiller installations were 1500m2, with a whitespace area of 365m2. This was a turnkey project, including uptime TIER III compliant detail design, civil and architectural works, complete Electromechanical Balance of Plant, c

34 views0 comments

Okan Saçlı

Jan 27, 2019

KORRY Button Tutorial

I've already published a short guide on how I make produce my korry type buttons. There is even a short video on my youtube channel on korry production. In this tutorial I will give provide more detailed descriptions and steps in the production. The end product will be like below. So please follow the steps provided and better improve on the way. #airbus #a320 #airbusa320 #homecockpit #homesimulator #simulation #electronics #turkish #engineering #challenge #3d #3dprinting #co

3,742 views11 comments
